Concrete Negative Side

Negative Side repair system components

Pro-Seal DP 36

Pro-Seal DP-36 Bonding and drying agent extracts fluid bond breaking contaminents and water migration in situ of concrete.

Pro-Seal 34

Pro-Seal DP 36

Pro-Seal 34 single component wet surface or under fluid sealant saturates oakum packing to be placed in leaking joints or cracks. Highly adhesive and elastic Pro-Seal 34 saturated oakum, moves with the joint to maintain water tight seals.

Pro-Seal Oakum

Pro-Seal DP 36

Pro-Seal Oakum

Pro-Seal Oakum packing is saturated with Pro-Seal 34 wet and underwater sealant prior to packing into leaking, joints, cracks and holes.

Pro-Seal PPW

A look at what is needed

Pro-Seal Oakum

Pro-Seal PPW 3 minute rapid set grout is applied in active waterflow repairs. PPW is for locking in the the Pro-Seal Oakum saturated with Pro-Seal 34 sealant, that is placed and packed into joints, cracks, or holes over Pro-Seal backer rod compressed (+25%).

Pro-Seal PPWs

A look at what is needed

Pro-Seal PPWs 15 minute rapid set grout is applied in damp or dry repairs, PPWs is for locking in the the Pro-Seal Oakum saturated with Pro-Seal 34 sealant, that is placed and packed into joints, cracks, or holes over Pro-Seal backer rod compressed (+25%).

A look at what is needed

Required materials for leaking concrete joint repairs: Pro-Seal DP-36 pre-treatment post cutting concrete or masonry joint to designed cut size and features.

Pro-Seal closed cell backer rod to be compressed 25%, leaving 1.5" to 2" free space depth, minimum .5" wide. Pro-Seal Oakum to be saturated with Pro-Seal 34 underwater single component Caulking. Pro-Seal PPW or Pro-Seal PPWs high density high compressive strength Nano grout. Call technical for guide specifications for our new project or repair site 800 349 7325.

Concrete Cutting Tool

Vaccum and clean joints Thoroughly

Concrete Cutting Tool

Use the most efficient concrete masonry tool to cut joints or cracks to a 2" depth (nominal) and a minimum of a .5"+ width (nominal +).

Cut Joints and Cracks

Vaccum and clean joints Thoroughly

Concrete Cutting Tool

Clean all loose debris and bond breaking materials from cut joints, cracks, and holes.

Vaccum and clean joints Thoroughly

Spray cleaned Joint with Pro-Seal DP 36

Using a wet vacuum, remove all dust, mud, and finer solid debris.

Spray cleaned Joint with Pro-Seal DP 36

Pack Joint Bottom with Closed Cell backer Rod

Spray cleaned Joint with Pro-Seal DP 36

If the crack, joint, or hole is wet spray it with Pro-Seal DP-36 bonding and drying agent. If the joint is dry or damp wet the area to be repaired with clean tap water to saturation and then apply

Pro-Seal DP-36 bonding drying agent.

Pack Joint Bottom with Closed Cell backer Rod

Place Pro-Seal Closed Cell Backer Rod such that it is compressed a minimum of 25% leaving 1 inch to 2 inches between the backer rod and the concrete surface.

Mix Pro-Seal Oakum with Pro-Seal 34

Pack Joint Bottom with Closed Cell backer Rod

Saturate Pro-Seal Oakum with

Pro-Seal 34 single component wet and underwater sealant to saturation .

Placing Pro-Seal 34 Saturared Pro-Seal Okum.

Pro-Seal 34 Wet and Underwater Sealant saturated Pro-Seal Oakum packed in place

Pack .5 inches of joint over backer rod with Pro-Seal 34 saturated oakum, leaving the top .5 inches

Pack .5 inched of cut keyway above the preplaced closed cell backer rod with Pro-Seal 34 saturated Pro-Seal Oakum. Leave the top .5 inches of the cut keyway open.

Pro-Seal 34 Wet and Underwater Sealant saturated Pro-Seal Oakum packed in place

Pro-Seal 34 Saturated Oakum should fill only 50% of the depth of the remaining joint, crack, or hole from from the top of the pro-Seal Backer Rod to the concrete surface.

Mix Pro-Seal PPW or PPWs

Pro-Seal 34 Wet and Underwater Sealant saturated Pro-Seal Oakum packed in place

Place Pro-Seal PPW or Pro-Seal PPWs

Mixed properlyappW or PPWs should be the consistency of dry potters clay ball or a bread dough ball.

Place Pro-Seal PPW or Pro-Seal PPWs

Use Pro-Seal PPW rapid set (3 minutes) for active leaks and Pro-Seal PPWs slow set (10 to 15 Minutes) for damp or dry leak repairs.

Tool Pro-Seal PPWs or PPWs

Place Pro-Seal PPW or Pro-Seal PPWs

Tool Pro-Seal PPWs or PPWs

Using the Pro-Seal 34 caulking tube tool the Pro-Seal PPW material to a concave finish by placiing the tube along the joint and turn the tube like a roller pin.

Broom Finishing

Place Pro-Seal PPW or Pro-Seal PPWs

Tool Pro-Seal PPWs or PPWs

Pull broom in one direction onlyleaving fne lines unidirection in the grouts surface. material will set in 3 to 15 minutes. Allow to cure.

Cycling

You will note, over the next 30 to 90 days after the repair, a dark light cyle in the concrete patch, this is the normal curing process. This cycling coloration will be dry and eventually fade away.

Recap

Cycling

Required materials for leaking concrete joint and crack repairs: Pro-Seal DP-36 pre-treatment post cutting joint to size. Closed cell backer rod to be compressed 25% leaving 1.5" to 2" free space minimum .5" wide. Pro-Seal Oakum to be saturated with Pro-Seal 34 underwater single component Caulking. Pro-Seal PPW or Pro-Seal PPWs high density high compressive strength Nano grouts. Call technical for guide specifications for our new project or repair site 800 349 7325.

Pro-seal AquAFlex and Pro-Seal AquaCrete

Pro-Seal AquaFlex

Pro-Seal AquaCrete

Pro-Seal AquaFlex is the final finish coat over a negative side repair, (stopping water leak in concrete against the water flow), water barrier and management repair on surfaces with anticipated high vibration, settling, or movement.

Find out more

Pro-Seal AquaCrete

Pro-Seal AquaCrete is for finishing coating negative side repairs (i.e. stopping water leak in concrete against the water flow), with anticipated high water ingress pressures.

Find out more

Pro-Seal Power Patch, repair for concrete, metal, & more

Pro-Seal PowerPatch

Pro-Seal PowerPatch Casting Grade

Pro-Seal PowerPatch Flexible

Pro-Seal PowerPatch is a rapid curing repair material that can be used on wet surfaces or underwater. When surfaces are wet pre-treat with Pro-Seal DP 36 a fluid extractant. the material is designed to structurally repair deep spalls and level very rough surfaces in harsh coating environments.

Find out more

Pro-Seal PowerPatch Flexible

Pro-Seal PowerPatch Casting Grade

Pro-Seal PowerPatch Flexible

Pro-Seal PowerPatch flexible is designed to be applied to dry and wet surfaces as well as through standing water if necessary (contact technical 800 349 7325). Pro-Seal PowerPatch Flexible will heal moving cracks and joints in industrial environments within 45 minutes. Pro-Seal PowerPatch Flexible can be packaged in pail kits or in 10 oz. tubes or 20 oz. kits.

Find out more

Pro-Seal PowerPatch Casting Grade

Pro-Seal PowerPatch Injection Grade

Pro-Seal PowerPatch Casting Grade is designed for structural repair of anchoring concrete where dismantling, shut down and stoppages are not practical. pro-Seal PowerPatch Casting Grade cures rapidly to a functional state without costly shut downs. Notice where installation is dangerous always follow Industrial safety guidelines and facility safety guidelines for your project site.

Find out more

Pro-Seal PowerPatch Injection Grade

Pro-Seal Aero-Graph Impeller & Metal Repairs

Pro-Seal PowerPatch Injection Grade

Pro-Seal PowerPatch Injection Grade material is designed to heal cracks in concrete where there are no other reasonable or better options. Contact technical 800 349 7325 for guide specifications for your project.

Find out more

Pro-Seal PowerPatch Zebra Muscle Barrier

Pro-Seal Aero-Graph Impeller & Metal Repairs

Pro-Seal Hot Foot Zebra Muscle Barrier Coating. Coat intake pipes or other structures to reduce or stop Zebra Muscle ingress. contact Technical 800 349 7325.

Find out more

Pro-Seal Aero-Graph Impeller & Metal Repairs

Pro-Seal Aero-Graph repairs worn metal impellers, propeller surfaces, and ball surfaces of balls in ball valves and other difficult to replace equipment.

Find out more

Liquid Steel Structural Repair

Repairs structure with up to 120K PSI strength. Conctact technicacl for more information 1 800 349 7325.

Find out more

Concrete curing, Polishing and surface drying prep

Pro-Seal Pro-Cure A Concrete Curing Agent

Pro-Seal ROCHard Concrete Polishing Agent

Pro-Seal Pro-Cure A Concrete Curing Agent

Pro-Seal ProCure A is a film building moisture trapping curing agent for concrete.

Find out more

Pro-Seal DryCrete Concrete Surface Drying Agent

Pro-Seal ROCHard Concrete Polishing Agent

Pro-Seal Pro-Cure A Concrete Curing Agent

Pro-Seal DryCrete is a surface dying agent to remove moisture from the surface of concrete to allow earlier coating and painting accesses. Pro-Seal DryCrete may also be used with curing agents when trying to achieve moisture balances over extended curing periods, contact technical 800 349 7325.

Find out more

Pro-Seal ROCHard Concrete Polishing Agent

Pro-Seal ROCHard is an easy way to gain a deep glossy finish on a steel finished concrete floor. All that is required, once floor is clean and prepared, is a commercial grade floor scrubber with red, green, and black pads and of course Pro-Seal ROCHard.

Find out more
